9299130NE



16Ah/LiCoxNiyMnzO


01
Model No.
9299130NE
02
Positive Material
LiCoxNiyMnzO
03
Typical Capacity
16 Ah
04
Cycle Life
1C-1C RT > 1500
05
Voltage
Average
3.7 V
Max.
4.2 V
Min.
2.8 V
06
Dimension
Thickness/Height
9.20 mm
Width
99.0 mm
Length
130.0 mm
07
Weight
< 240 g
08
Initial Internal Resistance
< 4 mΩ, 25℃
09
Energy/Rated Capacity
60.8 Wh
10
Energy Density
by Weight
246 Wh/Kg
by Volume
512 Wh/L
11
Charge
Max.C-rate
1C
12
Discharge
Max. Continuous C-rate
1C
Transient Peak Current
3C
13
Operating Temperature
Charging
0~45℃
Discharging
-20~55℃
14
Storage Temperature
-20~40℃
15
Humidity Range
< RH 45~85%
